Minelab Manticore
The Perfect Beast
Black Friday Deal
For Black Friday 2025 you can get the Manticore for just £1599, that's £200 off, with the option to buy additional accessory coils for only £100 each!
If you’ve been around metal detecting for even a short while, you’ve probably heard rumours from other detectorists about the New Minelab
and maybe even talk of a metal-detecting beast! Well, both of these rumours are true, as in September 2022 Minelab announced their new flagship coin and treasure detector, the Manticore.
The Manticore is a high-performance metal detector which sits in the higher echelons of the Minelab detecting hierarchy. This is the next generation of metal detector, both physically in its construction, and through its power and intelligence.
Technical Specification
| Feature | Detail |
|---|---|
| Weight | 1.3kg / 2.9lb |
| Composition | Telescopic/Collapsible, Carbon Fibre Shaft |
| Extended Length | 144cm / 56.7inch |
| Collapsed Length | 63cm / 24.8inc |
| Technology / Processing | Multi-IQ+ |
| Stock Coil | M11 11 Inch Double D |
| Waterproofing | 5 Metres / 16 Feet IP68 |
| Detecting Modes |
|
| Operating Frequencies |
|
| Target Identification | Conductive: 0-99 with ferrous indication |
| 2D ID Map | Two-Dimensional ID Map System with Target Trace |
| Sensitivity | 1 to 35 |
| Recovery Speed | 0 to 8 |
| Target Tones | 1, 2, 5 – Tone I 1, 2, 5 – Region All Tones |
| Target Volume | 0 to 25 |
| Target Pitch | 1 to 50 |
| Ground Balance | Automatic, Manual & Tracking |
| Noise Cancel | Automatic, Continuous Auto & Manual (-9 to +9) |
| Depth Indicator | 5 Levels |
| Audio Themes | Normal, Enhanced & Continuous |
| Volume Profiles | Simple, Medium & Rich |
| Ferrous Volume | 0 to 25 |
| Ferrous Pitch | 1 to 50 |
| Ferrous Limits | Upper: 0 to 14 I Lower: 0 to 9 |
| Ferrous Limits Custom | 1 to 4 |
| Flashlight | Low, Medium, High, & Off |
| Handgrip Vibration | On, Off |
| Battery | Internal Rechargeable Lithium-ion |
| Battery Runtime | Approx 9 Hours |
| Battery Charge Time | Approx 7 Hours |
| Included Accessories |
|
Physical Composition
The Minelab Metal Detector range is quite diverse in terms of aesthetics, in this regard they’ve always been very considerate, and not lazy when it comes to product design. If we compare for example the Go Find range, with their portable, boxy
style with that of the very, loud
and dramatic red, angular styling of the Vanquish range and then finally into the elegant, slimline
, cool grey styling of the Equinox series you can really see diversity in construction and market potential. We think Minelab have catered to another segment of the detecting community with the design of Manticore, we’ve reached what we would describe as, tactical
or stealth mode
and this is reflected in the almost military and advancing colour and construction.
NOTE: For the Manticore with accessories please choose the product listed at £1,799
